RAG in Practice: Implementing & Tuning a Production Pipeline

Continuing from
← Part 1: RAG 101: Designing Retrieval-Augmented Generation Pipelines
Now we're going from notebook → prod

---

1. Embedding at Scale

# nightly batch
python embed_corpus.py --input s3://docs --output s3://vectors

# webhook for fresh docs
python embed_doc.py new_doc.pdf

Storage Options

• FAISS flat
  Pros: Blazing local speed
  Cons: Single-box only

• PGVector
  Pros: SQL joins + ACID
  Cons: Network latency

• Qdrant
  Pros: gRPC, HNSW, multi-node
  Cons: New ops surface

---

2. Retrieval Tuning

Key Parameters

• k: 3–8
  Impact: Higher recall but higher cost

• Diversity: MMR, score-sum
  Impact: Better topic spread

• Chunk Size: 256–512 tokens
  Impact: Context fit vs. completeness

Store metadata={source_id, chunk_id} for traceability.

---

3. Prompt Patterns

• Stuff – Dump all retrieved chunks
• Refine – Iterative summarization
• Map-Reduce – Parallel processing + merge

"You are an expert assistant.
Using ONLY the CONTEXT below,
answer: {{question}}"

---

4. FastAPI Reference

from fastapi import FastAPI

app = FastAPI()

@app.post("/ask")
async def ask(payload: dict):
    """Handle RAG queries."""
    return await rag.run(payload["query"])

Deploy behind Ray Serve or SageMaker; autoscale on P95 latency.

---

5. Evaluation Suite

Key Metrics

• Exact Match / ROUGE-L
  Method: Synthetic Q&A pairs

• Faithfulness
  Method: LLM-as-judge, 100-sample audit

• Retrieval Recall
  Method: (gt ∩ retrieved) / gt

Track in Weights & Biases, Evidently-AI, or Prometheus + Grafana panels.

---

6. Cost & Latency Levers

• Use smaller embed models (e5-small-v2)
• Implement Redis-ahead cache (aim > 70% hit-rate)
• Batch LLM calls (≤ 8 queries)
• Two-tier RAG:
  Cheap retriever → Expensive reranker → LLM

---

7. Pre-Prod Checklist

• [ ] SLA doc signed
• [ ] CI embedding + lint
• [ ] Canary rollout / auto-rollback
• [ ] P0 alert on empty retrieval
• [ ] Data-retention & PII audit

---

8. Common Pitfalls

1. Stale embeddings
   → Schedule incremental jobs

2. Chunk bleed
   → Use overlap tokens or heading-aware chunks

3. Prompt overflow
   → Drop low-score chunks or switch to map-reduce

---

RAG turns static knowledge bases into living, conversational systems—without costly fine-tuning cycles. Nail retrieval, observe everything, and keep prompts lean.
